3,000 MT/ MonthSolar photovoltaic bracket is a special bracket designed for placing, installing and fixing solar panels in solar photovoltaic power generation system. Common materials include aluminum alloy, carbon steel and stainless steel. Photovoltaic brackets are special equipment designed and installed in solar photovoltaic systems to support, fix and rotate photovoltaic modules. They play a supporting and fixing role for the entire power station, ensuring that the photovoltaic power station operates stably and reliably under various complex natural conditions for more than 25 years.
Category One: Solar Photovotaic Carpot
Solar photovoltaic carport combines photovoltaic power generation with the carport roof. This is the simplest combination of photovoltaic and architecture. It can not only realize all the functions of a traditional carport, but also bring power generation benefits to the owners. Generally, steel structure brackets are used, which are simple, generous, fashionable and beautiful, and are clean and environmentally friendly new energy sources, effectively alleviating society's environmental and energy pressure.
Category Two: Solar Panel Ground Mounted Structure
The brackets of solar arrays are usually fixed by hot-dip galvanized steel products or stainless steel anchor bolts protruding from the reinforced concrete foundation. When a concrete foundation is used on the roof of a house, uncover part of the waterproof layer of the house and peel off the concrete surface. Weld the steel bars of the concrete base for the array to the steel bars of the patio. Afterwards, a secondary waterproofing treatment is carried out with a waterproof filler.
Category Three: Solar Panel Mounting Pole Structure
|
Product Name |
Ground Mounted Solar Panel Mounting Pole Structure |
|
Material |
Q235 SS304 SS316 |
|
Equipment |
80T/200T/250T/300T/500T/800T Stamping machine CNC & EDM & Bending. etc. |
|
OEM/ODM |
Available |
|
Panel Type: |
Framed & Frameless |
|
Wind load |
<=60m/s |
|
Tile Angle |
0-60 degree |
|
Surface treatment: |
Hod dipped galvanization >=65um for Q235 steel and Average Anodizing coating thickness >=8-10um |
|
Panel Orientation |
Landscape/portrait |
|
Packing |
15 years quality warranty, 25 years life span warranty |
Category Four: Roof Photovoltaic Bracket
The environment where roof photovoltaic brackets are installed includes sloped roofs and flat roofs. The installation must comply with the roof environment without damaging the inherent structure and self-waterproofing system. Roofing materials include glazed tiles, colored steel tiles, linoleum tiles, concrete surfaces, etc. Different bracket solutions are used for different roofing materials. There are different bracket systems for different roofing materials.
Packaging Reference:
Use custom pallets and film coverings to protect goods from damage in transit. The ground screws are packaged separately.
About us - Qingdao Altai Tower Co., Ltd
Qingdao Altai tower Co., Ltd. is a professional manufacturer of telecommunication tower, power tower and tower accessories, and has passed ISO, CE and other international authoritative certification, we have 23 international patents. We are committed to providing customers with the best telecommunication towers and the most professional telecommunication equipment optimization solutions. Many of our products have been exported to more than 100 different countries and regions, such as the United States, Middle East countries, Europe and so on, and have achieved very good market reputation in the local market.
Solar Carports Mounting Structure combines photovoltaic power generation with the carport roof is the simplest combination of photovoltaics and architecture. It can not only realize all the functions of a traditional carport, but also bring power generation benefits to the owners.
Solar photovoltaic bracket is a special bracket designed for placing, installing and fixing solar panels in solar photovoltaic power generation system. Common materials include aluminum alloy, carbon steel and stainless steel.
The single-column bracket only needs one single-row column support, and each unit has only a single-row bracket foundation. It mainly consists of columns, diagonal supports, guide rails (beams), component pressure blocks, guide rail connectors, bolt washers, nut sliders and other components.
The circumstance where roof photovoltaic brackets are installed includes sloped roofs and flat roofs. The installation must comply with the roof environment without damaging the inherent structure and self-waterproofing system. Roofing materials include glazed tiles, colored steel tiles, linoleum tiles, concrete surfaces, etc.
110kV electric towers serve an important role in regional transmission and distribution at moderate voltages and tower heights. Lower than 230kV or 500kV systems. Set in concrete piers or steel grillage foundations anchoring the tower base.
A 45-foot electric steel pole is a sturdy structure designed to support overhead power lines, telecommunication cables, or other utilities at a moderate height.
230kV transmission towers enable efficient heavy-duty electric power transmission and interconnection over long distances across a region. With appropriate design and fabrication, it can enjoy long life span and provide effective transmission capacity.
1. key Details:Place of Origin: Shandong, China (Mainland) Brand Name: Altai Tower or OEM Model Number: AT-G20 Surface treatment: Hot Dip Galvanizied or painted. 2.Packaging & Delivery: Packaging Details: Telecom tower will be bundled by Galvanized strapping as per client's requirements. Deliver: Shipped in 30 days after payment from Qingdao / designated port. Tower members: One steel tower is separated into several bundles. Bolts: Packing material is robust nylon bag or steel drum. 3. Technical Data 1. Design Code ALT/294/ASC-AC Structure Steel 2. Grade High Tensil Steel GB/T1591:Q345B, Q345C,Q3455D ASTM A572 Gr50 EN10025: S355JR, S355J0,S355J2 3. Design Wind Speed Max. 250 km/h 4. Allowable deflection 0.5 ~1.0 degree at operational speed 5. Tension strength (Mpa) 470~630 6. Yield strength (t≤16mm) (Mpa) 235 7. Elongation (%) 24 8. Impact strength KV (J) 27(20°C)---Q345B(S355JR) 27(0°C)---Q345C(S355J0) 27(-20°C)---Q345D(S355J2) Bolts & Nuts 9. Grade Grade 4.8, 6.8, 8.8 10. Standards for mechanical properties 10.1 Bolts ISO 898-1 10.2 Nuts ISO 898-2 10.3 Washers ISO 6507-1 11. Standards for Dimensions 11.1 Bolts DIN7990, DIN931, DIN933 11.2 Nuts ISO4032, ISO4034 11.3 Washers DIN7989, DIN127B, ISO7091 Welding 12. Method CO2 Shielded Arc Welding & Submerged Arc Welding(SAW) 13. Standard AWS D1.1 Marking 14. Method of marking of the members Hydraulic Press Stamping or Laser Engraving Galvanizing 15. Galvanization standard of steel sections ISO 1461 or ASTM A123 16. Galvanization standard of bolts and nuts ISO 1461 or ASTM A153 Test 17. Factory test Tensile test,Elements analysis, Sharpy test(impact test), Cold Bending, Preece test,Hammer test Capacity 18. Maximum Production Capacity 2,000 Metric Ton per Month Packaging Detail: With standard sea-worthy packaging or as per requirements. Hot-dip Galvanization: The galvanizing workshop we have invested in is equipped with equipment imported from Italy and is galvanized in strict accordance with the American ASTM A123 standard. 1 1 Why Choose Us? 1. Strict quality control system and abundant technical reserves have created world-class products.2. The factory has completed tens of thousands of project cases so far, so that we have a wealth of technical reserves.3. Facilitating supports and low labor cost make the product price have great advantages in the world.4. With a number of patented technologies and a mature drawing and drawing team, you can rest assured of your choice.5. China Power Grid Certification Level 1 supplier, you can safely choose and cooperate.6. We are not only manufacturers and suppliers, but also your partners and technical support. Full Experience in the Industry Mature Production Line 1 1 Sophisticated Equipments Professional Design & Engineering Team
