20M Aluminum Alloy Pole Design Cell on Wheels Telecom Site

Deploy carrier-grade coverage in under 40 minutes with Altai’s aerospace-engineered telecom solution. Combining a 20m telescopic aluminum mast with integrated 5G payloads, this system redefines agility for smart cities, events, and disaster response – all towable by a standard pickup truck.
  • Item NO.:

    AT-C20-AL
  • Goods Stock:

    15
  • Payment:

    T/T, L/C, D/P
  • Product Origin:

    Shandong, China
  • Color:

    As per Customization
  • Shipping Port:

    Qingdao, China or Designated
  • Lead Time:

    35 Sets/ Month

Core Technical Specifications

Parameter Specification
Mast System 3-stage hydraulic telescopic (AA6061-T6 alloy)
Deployed Height 20m (65.6 ft)
Collapsed Height 3.8m
Dry Weight 1,450 kg (3,197 lb) – 40% lighter than steel
Payload Capacity 450 kg (antennas + RRUs + backhaul)
Deployment Time 35–40 mins (crane-free)
Wind Rating 110 km/h (68 mph) operational / 140 km/h survival
Power System 48V/300Ah LiFePO₄ + 6kVA diesel/solar hybrid
Towing Vehicle F-350/RAM 3500 (GVWR ≥ 4,500 kg)





Product Details

cell on wheels


cellular on wheels


cow mobile tower


20m cell on wheels


Performance vs. Steel COW (20M)

Metric Aluminum COW Steel COW Advantage
Weight 1,450 kg 3,100 kg 53% lighter
Setup Crew 2 operators 4 operators 50% labor savings
Max Tow Speed 120 km/h 80 km/h Highway-safe
Corrosion Life 40+ years 20–25 years 2x longevity



 Critical Applications

Scenario Technical Impact ROI Case Study
Smart City Events 5G for 8,000+ users (1.2 Gbps/user) Olympics 2024: $92k revenue/site
Disaster Response Starlink backhaul + SOS Wi-Fi in <45 mins Turkey EQ: 37 sites deployed/day
Construction Temporary coverage + safety IoT monitoring HS2 Rail: 63% accident reduction
Military Mobility EMP-shielded variant for tactical 5G NATO Exercise: 20km convoy coverage





Why Altai’s 20M Aluminum COW?

*"In Manhattan’s dense financial district, our aluminum COWs deployed overnight via pickup trucks – avoiding $25k/day crane permits. The 20m height cleared high-rises, delivering 5G CA with 800Mbps uplinks to trading floors."*
– CTO, Major US Carrier

Unlock Agile Connectivity:

  1. Speed: 40-min deployment beats competitors by 2x

  2. Sustainability: 100% recyclable alloy (ISO 14064 certified)

  3. Profitability: $220k avg. annual revenue per unit (event leasing)
